STEP 32
(1) SLIDE ASSEMBLY
T-NUT 5/16
(3 PLCS)
BOLT WH 5/16x1/2
(3 PLCS)
13/16
2 5/8
5 5
1
3
T-NUT 5/16(3)
BOLT WH
5/16x1/2
(3)
7/16" DRILLING PATTERN
