STEP 28
(1) SWING BEAM ASSEMBLY
BOLT HEX 5/16x1 1/4
(4 PLCS)
WASHER SPLIT 5/16
(4 PLCS)
WASHER FLAT 8x27
(4 PLCS)
BOLT HEX
5
/16x1 1/4
(4)
WASHER
SPLIT 5/16
(4)
WASHER
FLAT 8x27
(4)
SWING BEAM ASSEMBLY
