Backyard 1705012 - Page 34

STEP 5
T-NUT 5/16
(4)
RIGHT
L
EFT
ASSEMBLE T-NUTS INTO BOARD BEFORE INSTALLATION.
INSIDE SURFACE.
BOLT WH
5/16x3 3/4
(4)
BOLT WH
5/16x3 1/2
(4)
LAG SCREW
WH 5/16x2
(10)
WASHER
LOCK EXT
8x19
(18)
T-NUT 5/16
(4 PLCS)
G2
G2
M9
M9
H5
M6
K2
BOLT WH 5/16x3 3/4
(4 PLCS)
WASHER LOCK EXT 8x19
(4 PLCS)
WASHER LOCK EXT 8x19
(2 PLCS)
LAG SCREW WH 5/16x2
(2 PLCS)
WASHER LOCK EXT 8x19
(2 PLCS)
LAG SCREW WH 5/16x2
(2 PLCS)
LAG SCREW WH 5/16x2
(4 PLCS)
WASHER LOCK EXT 8x19
(4 PLCS)
WASHER LOCK EXT 8x19
(2 PLCS)
LAG SCREW WH 5/16x2
(2 PLCS)
WASHER LOCK EXT 8x19
(4 PLCS)
BOLT WH 5/16x3 1/2
(4 PLCS)
G2 - WALL RAIL - W4L07153
1
"x5 1/4"x48 7/8" (24x134x1243)
(1)
H5 - FLOOR SUPPORT - W4L07131
1"x3 3/8"x48 7/8" (24x86x1243)
(1)
K2 - GROUND BOARD - W4L07123
5/8"x5 1/4"x89 3/8" (16x134x2270)
(1)
M6 - SAFETY RAIL - W4L07143
5/8"x3 3/8"x48 7/8" (16x86x1243)
(1)
M9 - WALL RAIL - W4L07146
5/8"x3 3/8"x48 7/8" (16x86x1243)
(2)
