Assembly Instructions
1
Attach Axle and Wheels
4
Assemble Right Cart Frame
3
Assemble Left Cart Frame
2
Please have your owner’s manual and model number available
for reference.
Note: The model number is printed on a label which can be
found on the inside door, back or side of the cart assembly.
Assembly Tips:
1. Select an area where you will assemble this product. To
protect components, choose a smooth surface that’s free
of cracks or openings.
2. Spread out all parts.
3. Tighten all hardware connections by hand first. Then,
before completing each step, go back and fully tighten
all hardware. Be careful not to over-tighten. That could
damage surfaces or strip threads.
4. For best results, complete each step in the order
presented.
To complete assembly you will need:
• (1) Leak detection solution (instructions on how to make
the solution are included in the “Operating Instructions”
section of this manual).
• (1) Precision-filled LP gas grill tank with Acme Type 1
external threaded valve connection (standard grill size)
(not included).
Typical assembly is approximately one hour.
DO NOT RETURN TO PLACE OF PURCHASE.
