Bad Boy MZ MAGNUM User Manual

PARTS SECTION
PAGE 38
Front Tire Assembly
DESCRIPTION
PART NUMBER
QTY
ITEM
Front Fork MZ
023-1000-00
11
Front Wheel Spanner
025-0008-00
1
2
1/2" x 7" Hex Bolt Grade 5
018-0004-00
1
3
1" Fine Thread 1/2" Nylock Nut
013-9004-00
14
1-14 x 5 Hex Bolt Grade 8 Zinc Yellow
018-0005-00
15
Caster Bearing 2009 & Up010-2000-0026
Rubber Bearing Cap
014-2050-00
17
MZ Caster Bearing Spacer025-0005-00
1
8
1/2" Nylock Nut (1/2 Jam)
018-4010-00
1
9
1 3/8" Wheel Bearing
022-7009-00210
11"x6"-5" Front Tire & Wheel Assembly
022-8049-00
111
1
3
9
2
4
8
6
5
7
Front Tire Assembly
10
10
11

Bad Boy MZ MAGNUM Specifications

General

Horsepower	25 HP
Deck Material	7-gauge steel
Spindle Material	Aluminum
Blade Tip Speed	18, 500 fpm
Cutting Width	60 inches
Cutting Height	1.5 - 4.5 inches
Warranty	2-Year Bumper-to-Bumper / 3-Year Engine
