Bad Boy RENEGADE Series Service Manual

PAGE 25
SECTION 14: ELECTRICAL SYSTEM
This electrical system is protected by a 25-amp main fuse
(pictured in Fig. 23).
A blown fuse usually indicates a problem within the
electrical system or an electrical component. Ensure the
battery terminals are tightly fastened. Never replace a
fuse with one of a higher amperage rating or ‘bypass’ a
fuse in any way. Doing so creates a significant fire hazard
and can cause severe damage to the mower’s electrical
components. If a fuse is repeatedly blowing, contact your
Bad Boy dealer.
To check for proper charging (13.6 - 14.2 volts DC), take
a voltage reading across battery terminals with engine at
full throttle.
Wire Harness Engine Adapter
25 Amp Fuse
Ensure Terminals are Tight
Fig. 24
Fig. 25

Bad Boy RENEGADE Series Specifications

General

Spindle Material	Cast Iron
Horsepower	37 HP
Cutting Width	72 inches
Transmission	Hydro-Gear ZT-4400
Cutting Height	1.5 - 5 inches
