PAGE 13
SECTION 8: MOVING INOPERABLE MOWER
8.1 Hopefully, you’ll never need to use this section of the manual. However, if you do, use extreme caution
when moving the mower! You should never try to push or pull the mower by hand. This could cause
serious bodily injury.
8.2 Do not tow the mower. Use a winch to load on a trailer for transporting.
Your Mower Weighs: ROGUE SERIES: 1400-1525 lbs.
***Weights fluctuate with the addition of accessories.
8.3 If it becomes necessary to move an inoperable mower, the drive pumps are equipped with bypass
valves that allow the drive tires to rotate freely. These bypass valves are located at the rear of the
pumps. Each require to loosen a 1/2 to a full turn to allow for proper bypass.
Valve Access
Bypass
Valve
To Next Page
