BAFANG 8FUN - Page 13

12
Picture 8
8.Fix the right crank on the bike with M8 inner hexagon screw. Tightening
force:35-40N.m (see picture 9)
Picture 9
9.Connect all cables for battery, display, speed detecting sensor and so
on (see picture 10-12)
M8 nut
left crank
right crank
M8 nut
