11
5. Hold the drive unit near to bicycle fork, force less than 5KG, tight 1st
nut M33 onto axle tube with force:30-40N.m (see picture 6)
Picture 6
6. Fix 2
nd
nut M33 onto axle tube, tightening force:30-40N.m(see picture
7)
Picture 7
7.
Fix the left crank on the bike with M8 inner hexagon screw. Tightening
force:35-40N.m (see picture 8)
M33 nut
M33 nut
