BAFANG DP C260.CAN User Manual

5
BF-UM-C-DP C260-EN November 2019
USER MANUAL FOR DISPLAY
7.6 NORMAL OPERATION
7.6.1 Switching the System ON/OFF
Press and hold (>2S) to power on the display, the HMI begin to show the boot up LOGO. Press
and hold (>2S) again can power off the HMI.
If the "automatic shutdown" time is set to 5 minutes (it can be set in function "Auto Off"), the HMI
will be automatically turned off within this set time, When it is not operated.
Welcome interface
7.6.2 Selection of Support Levels
When HMI power on, briefly press (<0.5s) or to select the assistance level (the number of
assistance level needs to be adapted to controller), The lowest level is Level 0, the highest Level is 5.
On the default is Level 1,“0”means no power assistance. The interface is as following:
