BAFANG H550 - Battery and Charger Specifications

8
BF-UM-C-BT F150-D-EN May 2023
8.3 SPECIFICATION
8.3.1 Battery
Primary Settings BT F150.D504.C BT F150.D672.C
Rated voltage 48 Vdc 48 Vdc
Nominal Capacity 10.5 Ah 14Ah
Rate Capacity 9.75Ah 13Ah
Energy 504 Wh 672Wh
Storage (At 35% SOC &-10° ~ 35 °C) 6 months 6 months
Cycle life 600 cycles 600 cycles
Dimensions (L * W * H) 367.4*90.3*91.5mm 367.4*90.3*91.5mm
Weight 2.7KG 3.3KG
8.3.2 Charger
• Operating voltage: 100 Vac–240 Vac,
50 – 60 Hz
• Rated output voltage: 54.6 V
• Output current: 2 A ± 0.2 A
• Minimum battery charge voltage: 27 ± 2 V
• Timing protection: 12 ± 0.5 h
• Operation temperature: 0 °C ~ +40 °C
• Storage temperature: -20 °C ~ +70 °C
• Shell size: 168mm*88mm*47mm
• Certificate: UL
