Nova-246 Outdoor LTE Base Station Installation Guide
7
Technical Specification 1.4
1.4.1 Hardware Specification
Item
Description
LTE Mode
FDD and TDD
LTE Bands
a
FDD
Band1/3/7/13/20/28
TDD
Band40/41/42/43/48
Channel Bandwidth
FDD
5MHz / 10MHz /15MHz / 20MHz
TDD
5MHz / 10MHz /15MHz / 20MHz on each carrier
MAX Output Power
43dBm/Ant
Receive Sensitivity
b
-102 dBm
Synchronization
GPS
Backhaul
1 Optical (SFP) and 1 RJ-45 Ethernet interface (1 GE)
2 Optical (SFP) interfaces
MIMO
FDD
DL 2 x 2
TDD
DL 2 x 2 on each carrier
Dimension
FDD
 Band1/3/7:
430mm (H) x 275mm (W) x 113mm (D)
 Band13/20/28:
430mm (H) x 275mm (W) x 137mm (D)
TDD
440mm (H) x 240mm (W) x 120mm (D)
Installation Type
Pole, wall
Antenna
External high gain antenna 17dBi
Overall Power
< 180W
Power
-48V (-57V to -42V) DC
AC adaptor (multi-national standards)
Weight
FDD
 Band1/3/7: 12kg
 Band13/20/28: 15kg
TDD
12kg
a
Different models support different frequency band.
b
The test method of receiving sensitivity is proposed by the 3GPP TS 36.104, which is based on 5MHz
bandwidth, FRC A1-3 in Annex A.1 (QPSK, R=1/3, 25RB) standard.
1.4.2 Software Specification
Item
Description
LTE Standard
LTE FDD 3GPP Release 12
Peak Rate
FDD
20MHz: DL 150Mbps, UL 50Mbps
