Nova-246 Outdoor Base Station Installation Guide
13
3. Base Station Installation
Unpacking 3.1
Before opening the box, make sure the package is in good condition, undamaged and
dried. During the unpacking, avoid potential damaging impacts from hits or excessive
force.
Once unpacked, check whether the quantity are consistent with the packing list.
Installation Procedure 3.2
The installation procedure of Nova-246 is given in Figure 3-1.
Figure 3-1 Installation Procedure of Nova-246
Install GPS Antenna 3.3
Installation requirements on the GPS antenna:
No major blocking from buildings in the vicinity. Keep the rooftop buildings a
distance away from the GPS. Make sure the space atop within 90 degrees (at least
45 degrees) is not blocked by any buildings.
Avoid installing the GPS in the vicinity of any other transmitting and receiving
