A. Oil Strainer Cleaning
• Oil Strainer is situated inside the plug as shown in the figure.
• Oil Strainer should be cleaned in accordance with periodic maintenance chart.
B. Oil Filter
• Replace the oil filter element assembly at every 10, 000 Kms. Ensure Engine oil level confirms to
maximum level indicated of dipstick on replacement of oil filter.
A. Location of
Oil strainer
B. Oil filter
A
B
3.3 Engine Oil-Checking / Replacement
59
