Bajaj Pulsar 150 2019 User Manual

11 12
Classic
Location of Parts
Battery
• It is located inside the ‘Side Cover’ LH.
• Always maintain electrolyte level in each cell
between max and min level lines.
• Always keep a watch on battery charge
level indicating icon, if it flashes (indicates
battery is in low charged condition), show
the vehicle to authorised BAL dealer.
Tool Kit Location
• It is located below seat.
• 2 rubber straps are provided to hold the
tool kit.
CAUTION : Always fit tool kit with rubber
straps.
TOOL KIT
BATTERY
Classic
CAUTION : Remove cover as described
above, otherwise the lugs may break.
Location of Parts
Removal of Side Cover LH or RH
• Insert key into cover lock & turn clockwise. &
pull ‘Side Cover’ out from the bottom.
• Pull front side (side towards Engine) of ‘Side
Cover’ to release Lug provided on ‘Side Cover’
from hole (A) provided on ‘Fuel Tank’.
• Slide the ‘Side Cover’ forward (towards the
engine) to release slot provided on rear side of
‘Side Cover’ from bracket with rubber cap (B)
provided on ‘Chassis’.
• Take out ‘Side Cover’.
Fitment of Side Cover LH or RH
• Match slot provided on rear side of ‘Side
Cover’ with bracket (B) provided on ‘Chassis’
and slide ‘Side Cover’ backward (towards Tail
lamp).
• Match Lug provided on front side of ‘Side
Cover’ with hole (A) provided on ‘Fuel Tank’
and press ‘Side Cover’ inside.
• Match the lock plate of ‘Side Cover’ properly
with bracket on ‘Chassis’ and Lock.
CAUTION: Fit cover as described above
to ensure proper fitment.
B
A
