Service Station Manual
3
4
5
6
7
8
9
10
2
1
11
12
16
17
18
19
20
21
14/15
13
17. Service Reminder ( ): 'Wrench' symbol glows when ODO following meter reading reaches to set Kms.
It indicates vehicle is due for periodic service.
This Icon will flash at
1st : 450 km -2nd : 4450 km,
3rd : 9450 km, 4th : 14450 km
and subsequently at each 5000 kms. Icon will continue to glow till it is reset. This icon is to be reset after service
is carried out. Service reminder reset is to be done at zero vehicle speed & zero engine speed.
18. Low Fuel Level Indicator: It blinks incase of low fuel level (1 bar or less)
19. Digital Clock: It indicates time in HR : MM (AM/PM)
20. Speedometer: Vehicle speed will be displayed in digital form in Km/h
21. Gear Indication: It will display gear position from 1 to 5 It will display 0 when vehicle is in neutral position.
Note :
After switching 'ON' the ignition switch, the indications will remain 'ON' till engine is started.
• High Engine Oil Temperature Indicator
• Low Battery Indicator
• Low Oil Pressure
• Malfunction Indicator
Instructions
Incase high engine oil temperature indicator, Low battery indicator, Low oil pressure indicator, Malfunction indicator,
ABS indicator gets ON during vehicle running, bring the vehicle to nearest BAL authorised workshop for inspection/ repair.
SPEEDOMETER INFORMATION
