BAKERS PRIDE – CONVECTION OVEN
Item Part # Description Item Part # Description
1 340115 MOTOR ½ HP 120V 50/60HZ 28 340289 DOOR SWITCH – PLUNGER STYLE
2 340136 MOTOR BRACKET 29 340162 KICK PLATE
3 340135 LIGHT BOX 30
390145
390148
340117
DOOR ASSY – R/H WITH GLASS
DOOR ASSY – R/H WITH SOLID
GLASS WINDOW ASSY ONLY
4 340283 LIGHT SOCKET PART OF ASSEMBLY 31 340116 HANDLE-OVEN DOOR
5 340283 LIGHT BULB PART OF ASSEMBLY 32
390144
390177
DOOR ASSY – L/H WITH GLASS
DOOR ASSY-L/H SOLID
6 340283 LIGHT COVER PART OF ASSEMBLY 33 340161 DOOR SEAL-SIDES
7 340341 POWER CORD 8 FEET 34 340160 DOOR SEAL-TOP, BOTTOM
8 340156 RIGHT SIDE PANEL-REAR 35
340315
340128
340253
340130
S3224A
340316
CHAIN, HT HD PRE STRETCHED
LINK ROD, ¼ x 3" W/EYE COUPLER
LINK ROD, ¼ x 20" W/EYE COUPLER
TURN BUCKLE
MASTER LINK
COUPLING ¼ - 20 EYE ROD
9 340155 RIGHT SIDE PANEL-FRONT 36 340157 DOOR CHAIN SPROCKET HOLDER
10 340281 TERMINAL BLOCK (8 WAY) 37 340218 CHANNEL SPROCKET SUPPORT
11 340134 IGNITION MODULE 38 340251 BUSHING, ½" DIA, BRONZE
12
39 340144 BLOWER BAFFLE
13
310354
310226
REGULATOR (NAT)
REGULATOR (LP)
40 340363 SNORKLE TUBE ASSY
14 N5235Z PIPE EXTENSION ¾ NPT x 19" (GAS INLET) 41 310912 BLOWER WHEEL
15 340267 SOLENOID, FJ GAS 42 300186 BOLT, ¼ - 20 x 5", HEX HEAD
16
340361
PILOT VALVE –
1
/
8
NPT x
1/4
CC x 90
43 340327 SPACER TUBE
3
/
8
" O.D. x 4-¼" S/S
17
301034
301050
ORIFICE HOOD – #31 (45,000 BTU NAT)
ORIFICE HOOD – #50 (45,000 BTU LP)
44 340222 DIVERTER-BOTTOM
18 311028 ADAPTER –
1
/
8
NPT Ex
3
/
8
-27 STRAIGHT 45 340223 DIVERTER-SIDES
19 340362
MANIFOLD PIPE
46 340221 DIVERTER-TOP
20 340617 CONTROL PANEL 47 340122
LEG 6" S/STEEL – WITH ADJUSTABLE FOOT
(TSCV-2)
21 340273 DECAL (CONTROL PANEL) 48 340180 LEG PLATE ASSY (TSCV-2)
22 340285 INDICATOR LIGHT 49 340364 BURNER
23 340294 KNOB-THERMOSTAT
50
NAT
340131
300227
PILOT, 6S30-2
PILOT BELL ORIFICE – 3/6 CC #26 (NAT)
24
340284
340287
340288
SWITCH, FAN-2 SPEED
SWITCH, LIGHT – MOMENTARY OVEN
LIGHT SWITCH
SWITCH, POWER – 3 POSITION, ON OFF
COOL DOWN
50
LP
340131
300226
PILOT, 6S30-2
PILOT BELL ORIFICE – 3/ 16 CC #16 (LP)
25 340262 KNOB-TIMER 51 340170 FRONT BAFFLE-OVEN
26 340261 TIMER 52
340124
340123
RACKGUIDE –R/H
RACKGUIDE –L/H
27 340132 THERMOSTAT 53 340125
RACK
