Page 8 56016-01_97_A
Serial Deluxe Panel Configurations
Time
Warm Blower Light
Mode/Prog
Time Warm Blower Light
Cool
Mode/Prog
Jets 1 Jets 2
VL801D (Serial Deluxe)
PN 54108 with Overlay PN 10763
s Connects to Main Board terminal J1 only*
SETUP 1
BlowerTime
Warm
Mode / Prog Cool Jets 1
Light
Jets 2
VL802D
PN 54528 with Overlay PN 11789
s Connects to Main Board terminal J1 only*
* Panels with back-lighting (bulbs installed) should never be plugged into J2. Use J1 only.
If the backlight bulbs are removed, then both J1 and J2 may be used.
