Baldor BC142 - Field Connection (Shunt Wound Motors Only)

6.2 Ground Connection – Connect the ground wire (earth) to the control chassis.
6.3 Permanent Magnet (PM) Motor Connection – Wire the motor armature positive lead (+) to Terminal “A+”
(Armature Fuse) and the negative lead (-) to Terminal “A-”, as shown in Figure 1, on page 10. On Catalog
Nos. BC142 and BC142-6, be sure Jumper J2 is set to the corresponding motor voltage, as described in
Section 7.2, on page 20. Be sure the correct Plug-In Horsepower Resistor® is installed, as described in
Section 9, on page 21.
6.4 Motor Field Connection (Shunt Wound Motors Only)
6.4.1 Full Voltage Field – Wire the field positive (+) lead to Terminal “F+” and the negative lead (-) to
Terminal “F-”, as shown in Figure 1, on page 10, and as described in Table 4.
6.4.2 Half Voltage Field – For 90 Volt DC motors with 50 Volt DC fields and 180 Volt DC motors with 100
Volt DC fields, wire the field positive lead (+) to Terminal “F+” and the negative lead (-) to Terminal “L1”
(Line Fuse), as described in Table 4.
Notes: 1. Do not connect motor armature leads to Terminals “F+” and “F-”. 2. Do not use Terminals “F+”
and “F-” for any purpose other than to power the field of a shunt wound motor. 3. Shunt wound motors
may be damaged if the field remains energized without armature rotation for an extended period of time.
14
Catalog No. AC Line Input Voltage (Volts AC) Armature Voltage (Volts DC) Field Voltage (Volts DC) Terminal Connections
BC141 115 0 - 90
100 F+, F-
50 F+, L1
BC142 208 / 230
0 - 180 200 F+, F-
0 - 90* 100 F+, L1
BC142-6
115 0 - 90
100 F+, F-
50 F+, L1
208 / 230 0 - 180 200 F+, F-
208 / 230 0 - 90* 100 F+, L1
TABLE 4 – FIELD CONNECTION (Shunt Wound Motors Only)
* Step-down operation.
