1-4 General Information
Specifications
Horse Power 0.5 - 1 HP @ 115VAC, 1PH
0.5 - 5 HP @ 230VAC, 3PH
1 - 5 HP @ 460VAC, 3PH
Input Voltage 95 - 127 VAC, 50/60Hz, Single Phase
187 - 253VAC, 50/60Hz, Three Phase
342 - 506VAC, 50/60Hz, Three Phase
Phase Imbalance
(3Phase Only)
±2%
Input Frequency 50/60Hz (±10%)
Enclosure NEMA 1
Output Voltage 0 to Maximum Input AC Voltage
Output Frequency 0.1 to 400 Hz
Output Current See Control Rating Table
Service Factor 1.0
Duty Cycle Continuous
Overload Capacity See Control Rating Table
Control Method Voltage Vector PWM
Carrier Frequency 9.2kHz
Frequency Resolution 0.05Hz
V/Hz Ratio 0.24 - 8.85 (230VAC)
0.48 - 17.69 (460VAC)
Output Transistor Type IGBT (Insulated Gate Bipolar Transistor)
Transistor Rise Time
2500Volts/msec (dv/dt)
Torque Boost Standard (automatic adjustment to load)
Manual (0-15% of input voltage)
Volts/Hertz Pattern Linear to Squared Reduced (in 6 patterns)
Accel/Decel Time 0.1 to 600 seconds (for 2 assignable)
Base Frequency 26 to 960 Hz
Dynamic Brake Torque Up to 60% for 6 seconds
