– 12 –
The USB port is on the left. Sedation data can be saved
to a USB stick. For this, the operator should click on the
“Export data” button in the “Recent patients” menu item.
NOTE FOR THE OPERATOR:
USB stick le format: FAT32.
Possible sizes of up to 64 GB.
Fig. 7: Baldus® Touch, view of the left side
Fig. 8: The full Baldus® Touch system in the Baldus® All-in-One-Cart
BACK FRONT
All-in-One-Cart
N
2
O pressure hose
O
2
pressure reducer N
2
O pressure reducer
O
2
pressure hose
N
2
O compressed
gas cylinder
O
2
compressed
gas cylinder
Oxygen-nitrous oxide mixer
Breathing bag
Scavenger
system
Gas supply hose
(spiral hose)
Vacuum
hose
