Function Description
Output buffer, configuration and explanation
Description of
Output Buffer
(continued)
Sub- Meaning Function Description
address
02Hex Start address Address at which reading from or writing to the Data carrier
(Low Byte) begins.
(The Low Byte includes the address range from 0 to 255).
or Start address Address for the Auto-Read function, starting at which the code
(Low Byte) tag is to be read. The value is stored in the EEPROM. (The Low
Byte covers the address range from 0 to 255).
or Program No. Number of the program to be stored in the EEPROM in
conjunction with command ID 06
Hex for Mixed Data Access
function (values between 01
Hex and 0AHex are allowed!).
or Program No. Number of the program stored in the EEPROM for read or write
operations in conjunction with command ID 21
Hex or 22Hex for the
Mixed Data Access function.
or Data for writing to the Data carrier
or Program data for writing to the EEPROM.
03Hex Start address Address for reading from or writing to the Data carrier (the High
Byte (High Byte) is additionally used for the address range from 256 to 8,191).
or Start address Address for the Auto-Read function, starting at which the code
(High Byte) tag is to be read. The value is stored in the EEPROM (the High
Byte is also required for the address range from 256 to 8,191).
or Data for writing to the Data carrier
or Program data for writing to the EEPROM.
(continued next )
Please note the
basic procedure on
14 and 29...35
and the examples on
pages
36...53.
C60_2-019_818217_0806-e.p65
20
english20
Function Description
Output buffer, configuration and explanation
Description of
Output Buffer
(continued)
Sub- Meaning Function Description
address
04Hex No. of bytes Number of bytes to read or write beginning with the start address
(Low Byte) (the Low Byte includes from 1 to 256 bytes).
or Data for writing to the Data carrier
or Program data for writing to the EEPROM.
05Hex No. of bytes Number of bytes to read or write beginning with the start address
(High Byte) (the High Byte is additionally used for the range between 257 and
8,192 bytes).
or Data for writing to the Data carrier
or Program data for writing to the EEPROM.
06Hex Data for writing to the Data carrier
or Program data for writing to the EEPROM.
... Data for writing to the Data carrier
or: Program data for writing to the EEPROM.
Last byte
2nd Bit header The data are valid if the 1st and 2nd bit header are identical.
or Data for writing to the Data carrier
or Program data for writing to the EEPROM.
Please note the
basic procedure on
14 and 29...35
and the examples on
pages
36...53.
