Balluff BIS C-6002 User Manual

23
23
english
Sub- Meaning Function Description
address
01Hex Error code (continued)
02
Hex Read error.
03
Hex Data carrier was removed from the active zone of the read/write
head while it was being read.
04
Hex Write error.
05
Hex Data carrier was removed from the active zone of the read/write
head while it was being written.
07
Hex AV bit is set but the command designator is missing or invalid.
or Number of bytes is 00
Hex.
09
Hex Cable break to select read/write head, or head not connected.
0C
Hex The EEPROM cannot be read/programmed.
0D
Hex Faulty communication with the Data carrier.
Note: Verify installation criteria or distance between data carrier
and read/write head.
0E
Hex The CRC of the read data does not coincide with the CRC of
the Data carrier.
0F
Hex Contents of the 1st and 2nd bit header (1st and last bytes) of
the output buffers are not identical (2nd bit header must be
served).
11
Hex Invoking a function that is not possible, since the processor is in
“compatible with BIS C-6_2” mode.
12
Hex Copying is not possible, since a command is already started
on Head 2.
or: Data Data which was read from the Data carrier.
(continued on next )
Function Description
Input buffer, configuration and explanation
Description of
Input Buffer
(continued)
Please note the
basic procedure on
14 and 29...35
and the examples on
pages
36...53.
C60_2-019_818217_0806-e.p65
24
english24
Function Description
Input buffer, configuration and explanation
Description of
Input Buffer
(continued)
Sub- Meaning Function Description
address
02Hex Data Data which was read from the Data carrier.
... Data Data which was read from the Data carrier.
Last byte
2nd Bit header The data are valid if the 1st and 2nd bit headers are in
agreement.
or Data Data which was read from the Data carrier.
Please note the
basic procedure on
14 and 29...35
and the examples on
pages
36...53.
