Balluff BIS C-6002 User Manual

45
45
english
01
Hex
Command designator 11
Hex
02
Hex
Start address Low Byte 0A
Hex
03
Hex
Start address High Byte 00
Hex
04
Hex
No. of bytes Low Byte 11
Hex
05
Hex
No. of bytes High Byte 00
Hex
00/07
Hex
CT-Bit to 0 (32 Byte block size),
set AV-Bit
00
Hex
/07
Hex
set AA-Bit
01...06
Hex
Enter the first 6 data bytes
00
Hex
/07
Hex
Invert TO-Bit
01...06
Hex
Copy the first 6 data bytes
Process subaddresses of the output buffer:
00
Hex
/07
Hex
Invert TI-Bit
01...06
Hex
Enter the second 6 data bytes
00
Hex
/07
Hex
Invert TO-Bit
Example No. 8
For configuring with
double bit header!
Function Description
Examples for protocol sequence
Copy 17 bytes starting at data carrier address 10
(data carrier type with 32-byte block size):
Data from the data carrier in front of Head 1 are read and written to the same memory lo-
cation in the data carrier in front of Head 2. Data transmission can be started even while
the data carrier in front of Head 1 is being read. This is indicated by the TO bit in the input
buffer.
During data transmission ("toggling" of the TI bit / TO bit), and only then are the bytes read
written to the data carrier in front of Head 2. The AE bit is not set until the write process at
Head 2 has been successfully completed. Any errors at Head 2 are indicated by the AF bit
in the bit header for Head 1.
Host:
1.) Process subaddresses of the output buffer in
the order shown:
BIS C-60_2 Identification System:
2.) Process subaddresses of the output buffer in
the order shown:
3.) Process subaddresses of the input buffer:
4.) Process subaddresses of the input buffer:
Continued on next
.
C60_2-019_818217_0806-e.p65
46
english46
Example No. 8
(continued)
For configuring with
double bit header!
Function Description
Examples for protocol sequence
8.) Process subaddresses of the input buffer:
6.) Process subaddresses of the input buffer:
7.) Process subaddresses of the input buffer:
5.) Process subaddresses of the input buffer:
01...06
Hex
Copy the second 6 data bytes
Process subaddresses of the input buffer:
00
Hex
/07
Hex
Invert TI-Bit
01...05
Hex
Enter the remaining 5 data bytes
00
Hex
/07
Hex
Invert TO-Bit
01...05
Hex
Copy the remaining 5 data bytes
Process subaddresses of the output buffer:
00
Hex
/07
Hex
Invert TI-Bit
00
Hex
/07
Hex
Set AE-Bit
9.) Process subaddresses of the output buffer:
00
Hex
/07
Hex
Reset AV-Bit
10.)Process subaddresses of the input buffer:
00
Hex
/07
Hex
Reset AA-Bit and AE-Bit
