1.1 Validity
This guide provides all of the information required to safely
use the BOS R090K-… diffuse sensor
It applies to the following models:
– BOS R090K-PU-RD10-S49
Order code: BOS029W
– BOS R090K-NU-RD10-S49
Order code: BOS029T
– BOS R090K-PU-RD11-S49
Order code: BOS029N
– BOS R090K-PU-ID10-S49
Order code: BOS02AY
– BOS R090K-NU-ID10-S49
Order code: BOS029R
– BOS R090K-PU-ID11-S49
Order code: BOS029U
– BOS R090K-NU-ID11-S49
Order code: BOS029P
– BOS R090K-PU-RD10-S75
Order code: BOS02AJ
– BOS R090K-NU-RD10-S75
Order code: BOS02AE
– BOS R090K-PU-ID10-S75
Order code: BOS02AH
– BOS R090K-NU-ID10-S75
Order code: BOS02AC
– BOS R090K-PU-RD11-S75
Order code: BOS02A9
– BOS R090K-PU-ID11-S75
Order code: BOS02AF
– BOS R090K-NU-ID11-S75
Order code: BOS02AA
– BOS R090K-PU-RD10-02
Order code: BOS02AM
– BOS R090K-NU-RD10-02
Order code: BOS02A8
– BOS R090K-PU-RD11-02
Order code: BOS029Z
– BOS R090K-NU-RD11-02
Order code: BOS029Y
– BOS R090K-PU-ID10-02
Order code: BOS02AL
– BOS R090K-NU-ID10-02
Order code: BOS02A1
– BOS R090K-PU-ID11-02
Order code: BOS02AK
– BOS R090K-NU-ID11-02
Order code: BOS02A0
Read this guide and the other applicable documents
completely before installing and operating the product.
Original User’s Guide
This guide was created in German. Other language
versions are translations of this guide.
© Copyright 2021, Balluff GmbH
All content is protected by copyright. All rights reserved,
including the right to reproduce, publish, edit and translate
this document.
1.2 Other applicable documents
Additional information about this product can be found at
www.balluff.com on the product page, e.g.in the
following documents:
– Data sheet
– Declaration of Conformity
– Disposal
1.3 Symbols and conventions
Individual action instructions are indicated by a preceding
triangle.
► Instruction 1
Action sequences are numbered consecutively:
1. Instruction 1
2. Instruction 2
Note, tip
This symbol indicates general notes.
1.4 Explanation of the warnings
Always observe the warnings in these instructions and the
measures described to avoid hazards.
The warnings used here contain various signal words and
are structured as follows:
SIGNAL WORD
Type and source of the hazard
Consequences if not complied with
► Measures to avoid hazards
The individual signal words mean:
NOTICE
Identifies a danger that could lead to damage to or
destruction of the product.
CAUTION
The general warning symbol together with the signal
word CAUTION indicates a hazard which can lead to
slight or moderate injuries.
DANGER
The general warning symbol in conjunction with the
signal word DANGER identifies a hazard which, if not
avoided, will certainly result in death or serious
injuries.
1
About this Guide
BOS R090K-_U-_ D1_-S49/S75/02
