mvBlueGEMINI Technical Manual (EN) v2.6
TECHNICAL DATA 12
Pin
Signal
Color
11
SPSIO5
gray/pink
12
NC
red/blue
7.2.1.1 Pinning of the fitting cable KS-M12-PWR-IO
Pin
Color
1
white
2
brown
3
green
4
yellow
5
gray
6
pink
7
blue
8
red
9
black
10
violet
11
gray/pink
12
red/blue
7.2.1.2 Characteristics of the I/Os
• SPSIO0 - SPSIO5 are digital in-/outputs. Each of them could be used as an input, output,
trigger line or for controlling flash lights.
• The inputs switch at approx. 11.3V (supply voltage > 18V; i.e. PLC).
• The inputs switch at approx. 50% of the supply voltage (supply voltage <= 18V).
• Max. output current for each output is 200mA.
• Current limited output (< 450mA)
• 5 μs input filter for spike suppression
• Reverse polarity protection
• Overtemperature protection
