Page 11 MODEL 205 ce
SECTION 11 - SPECIFICATIONS
AMPLITUDE RANGE:
English: (205 ce) mils pk-pk (peak-to-peak) Displacement
in/sec pk (peak) Velocity
g’s pk (peak) Acceleration
Note: Very Low Range in units of 0.001 g’s, 0,001 in/sec, & micro-inches
Metric: (205M ce) Displacement micrometers (µm) peak-to-peak
Velocity millimeters-per-second (mm/sec) peak
Acceleration g’s millimeters-per-second squared (mm/sec
2
) peak
Note: Very Low Range in units of 0.001 g’s, 0,001 mm/sec, & mm/sec
2
RANGE: Four selectable ranges with over-range indication for each range
MODEL 205 English 205M Metric
High Range 200 = 0 to 199.9 2000 = 0 to 1999
Medium Range 20 = 0 to 19.99 200 = 0 to 199
Low Range 2 = 0 to 1.999 20 = 0 to 19
Very Low Range 0 to 199.9 0 to 199.9
SENSITIVITY:
Displacement: 0.000001 inch (0.001 mil) (1 micro-inch) (0.0254 µm)
Velocity: 0.001 inch/sec (0.02 mm/sec)
Acceleration: 0.001 G
ACCURACY: 5% Full Scale instrument [see performance specifications on pickup]
FREQUENCY RANGE: 600 to +420,000 rpm (10 to +7,000 Hz)
DISPLAY: 3 ½ digit, numeric LCD (with Low Battery indicator)
INPUT: Industrial ICP Accelerometer (100 mV/g)
OUTPUT: Signal for Headphones 1/8" Mono jack
CONTROLS: Color-coded Function pushbuttons for all measurements
POWER: Four Size AA standard alkaline batteries 1.5 Volts
OPERATING
TEMPERATURE: 32E to 122EF (0E to 50EC)
ENVIRONMENTAL: Relative humidity 0-95% non-condensing
DIMENSIONS:
Model205 ce 7.67" H x 3.97" W x 1.73" D (19.5 x 10.1 x 4.4 cm)
Carrying Case 13.5" H x 10.5" W x 4.5" D (34.3 x 26.7 x 11.4 cm)
WEIGHT: Unit & standard accessories 5 lbs (2.3 kg)
Unit & pickup <2 lbs (<1 kg)
Pickup Specification - Model 601
SENSITIVITY (±10%, 25EC) 100 mV/g
ACCELERATION RANGE: 80g peak
AMPLITUDE NON-LINEARITY 1%
FREQUENCY RESPONSE
±10% 0.7 - 9,000 Hz
±3 dB 0.4 - 14,000 Hz
RESONANCE FREQUENCY 30 kHz
TRANSVERSE SENSITIVITY 5% of axial
POWER REQUIREMENT 18 - 30 VDC
GROUNDING Case isolated, internally shielded
TEMPERATURE RANGE: -50E to +120EC
VIBRATION LIMIT 500 g peak
SHOCK LIMIT: 5000 g pk
SEALING Hermetic
WEIGHT 62 grams
CASE MATERIAL 316L Stainless Steel
MOUNTING 1/4-28 UNF tapped hole
CONNECTOR TYPE: 2-pin, MIL-C-5015 Connector
