Programming
Agitation Programming continued
Notes on Agitation Programming
There are a number of different modes
available for motor programming:
1. Forwards - Pause - Backwards
FWD T = XXs
PAUSE T = XXs
REV T = XXs
2. Forwards - Pause
FWD T = XXs
PAUSE T = XXs
REV T = S0
3. Forwards
FWD T = XXs
PAUSE T = S0
4. Pause - Backwards
FWD T = S0
PAUSE T = XXs
REV T = XXs
5. Backwards
FWD T = S0
PAUSE T = S0
REV T = XXs
The minimum pause time that can be
programmed between forward and backwards
is 2 seconds. The maximum time is 239
seconds.
Cylinder speed is programmed during cycle
programming. In this mode, each step can be
programmed with different values if desired.
B&C Stock Agitation Assignments
9
Agitation Forward Pause Reverse
1 16 4 16
2 4 16 4
3 5 115 5
14 0 0 1
15 1 0 0
Agitation 1 - used for normal wash agitation.
Agitation2 - used for gentle wash agitation.
Agitation3 - used for soak formulas
Agitation14 - Used for Unroll cycles (reverse
only)
Agitation15 - Used for Spin cycles (forward
only)
