B&K Reference 220M - Outputs

Page 7
13005 rev 0004
)LJXUH'
Outputs
Five wa
y
bindin
g
posts are provided. One pair for each channel. The
y
are desi
g
ned to
accept a banana-t
y
pe plu
g
or spade lu
g
connector (shown below) and are color coded
for eas
y
identification. The red (+) post should alwa
y
s be connected to the speakers (+)
jack. The black (-) post should alwa
y
s be connected to the speakers (-) jack.
Spade connector Banana
j
ack
Here is a t
y
pical amplifier setup
The Reference 220M amplifier has two sets of bindin
g
posts on it. The
y
are paralleled
inside the amplifier.
The Channel 3 output is used for normal operation.
The amplifier comes standard with a Channel 1 and Channel 3 output. The Channel 3
output is used for normal operation, but
y
ou can use the Channel 1 output to connect to
another speaker in parallel.
