Parameter condition
Min
Typical
Max
Unit
DC3.3V（With an internal pressure regulator
and integrate CMOSPA）
3.0
3.3
3.6
V
Digital I/O power supply voltage
1.76
1.8-3.3
3.3
mA
DC_IO_33
（
3.3V I / O rated electric
current
）
50
mA
Electrostatic protection（VESD）
2000
V
RF performance
Description
Typical value
Unit
Operating frequency
2400-2483.5 or
5180-5825
MHz
Output power
In 11a mode, the PA output power is
14±2
dBm
In 11n mode, the PA output power is
14±2
dBm
In 11g mode, the PA output power is
15±2
dBm
In 11b mode, the PA output power is
16±2
dBm
Bluetooth output power
7±2
dBm
Receiving sensitivity
CCK, 1 Mbps
＜＝-90
dBm
CCK, 11 Mbps
＜＝-85
dBm
6 Mbps (1/2 BPSK)
＜＝-88
dBm
54 Mbps (3/4 64-QAM)
＜＝-70
dBm
HT20 (MCS7)
＜＝-67
dBm
Bluetooth sensitivity
＜＝-92
dBm
