Baofeng G11S - Key Controls and Indicators

11
1.
Antenna
2.
LED Flashlight
3.
Power Switch/ Volume control
4.
Led: transmission (red) / reception (green)
5.
[LAMP]: Press the key once to turn on the flashlight, Press and hold the key again to flash the flashlight, and
press the hand again to turn off the flashlight; Press and hold the key to turn on the audible and visual alarm
function
6.
[PTT]:Transmit key, hold the key to speak, release the key after speaking, and receive incoming calls;
7.
FM: Press to turn on the radio function, and press again to turn off the radio function;
8.
[SCAN ]: Press to send a CALL ALERT signal; Press and hold to enter SCAN mode.
9.
[MONI ]: Press to enter weather forecast mode; Press and hold to enter MONITOR mode.
10.
Battery release latch
11.
Belt clip
12.
Charging indicator: The red light is always on during charging, and the green light is always on when charging is
full.
13.
Micro-USB Charging Port: DC5V USB input
14
Speaker
15.
External Speaker/Microphone Jack: allows the connection with external devices such as headsets,
microphones.
16.
LCD Display
17.
+/- keys: push to select functions or Menu. Channel mode, press + to switch up the channel; press - to switch
channel down.
18.
Menu: press to enter the Menu functions and to confirm your selections.
19.
[A/B ] In standby mode, press this key to switch between main/sub channels between A/B channels. Press
and hold this key to lock or unlock the keyboard. Menu mode, Press the key to exit the menu; Press to enter
SCAN mode. Press and hold to turn KEY LOCK on/off.
