Baofeng G11S - LCD Display Elements

12
4.2 LCD Display
1. Call Tone (Off, 1–10)
10. Narrowband indicator (working at 12.5KHz)
2. VOX(OFF,1-5)
11.CTC Indicator(67.0-254.1)
3. Dual Channel Monitor(ON/OFF)
12.DCS Indicator(D023I/N-D754I/N)
4. Keypad Lock
13. Battery Indicator (3 Battery Levels)
5. A Channel number (1-22) or menu number (1-17)
14. The last two digits of RX/TX frequency (4-5 digits after the
decimal point)
6. A Channel arrow pointer
15. Frequency/channel alias display area
7.B Channel number (1-22)
16. The last two digits of RX/TX frequency (4-5 digits after the
decimal point)
8. B Channel arrow pointer
17. Transmit power indicator (half grid for low power, full grid for
high power)
9. Low power indication
18. Status (Transmit/ Receive)
