Getting to Know the Radio
Radio Overview
1. Antenna
2. FlashlightCall Button
3. MONI Button (Monitor)
4. PTT Button (Push-To-Talk)
5. VFO / MR Button
(Frequency Mode/ Channel Mode)
6. LED Indicator
7. Strap Buckle
8. Accessory Jack
9. A / B Button
(Frequency Display Switch)
10. Band Button (Not Present on Recent Models)
11. Numeric Keypad
12. Speaker & Microphone
13. Battery Pack
14. Battery Contacts
15. Battery Remove Button
