Baofeng UV-5RV2+ - DTMFST (DTMF Side Tones)

http://www.baofengradio.us 53
http://baofengradio.us
Menu Item
Shortcut
Description
DTMFST
16
DTMF Side Tones: Determines when DTMF Side Tones can be heard from the transceiver speaker.
Availability: Global
Settings/Notes
OFF [0] | DT-ST [1] | ANI-ST [2] | DT+ANI [3] Default: DT+ANI
OFF: No DTMF Side Tones are heard.
DT-ST: Side Tones are heard only from manually keyed DTMF codes.
ANI-ST: Side Tones are heard only from automatically keyed DTMF codes.
DT+ANI: All DTMF Side Tones are heard.
Note: Requires the transceiver to be in transmit mode.
Note: The mic can pick up the side tone and if the volume loud enough, it will overdrive and/or distort the transmitted DTMF
tones.
Note: (≤ BFB231) [MENU]=A, [▲]=C, [▼]=B, [EXIT]=D (†)
Note: (≥ BFB238) [MENU]=A, [▲]=B, [▼]=C, [EXIT]=D (†)
Note: (≥ BFS311) [MENU]=A, [▲]=B, [▼]=C, [EXIT]=0
(†) The Side Tone heard for 'D' is '0' (zero) but 'D' is sent over-the-air
