Barbecook MAJOR KIWI - Page 2

2
MAJOR
KIWI
223.5030.000
0 227.1420.050
1 227.5030.010
2 227.1400.050
3 227.1601.050
4 227.1895.050
5 227.2020.018
6 227.2290.045
7 227.2200.100
8 227.2285.016
9 227.2420.050
10 227.4805.050
11 227.2200.500
12 227.2200.200
MAJOR
LAGOON
223.5060.000
0 227.1420.050
1 227.5030.010
2 227.1400.050
3 227.1601.050
4 227.5060.020
5 227.2020.018
6 227.50 60.030
7 227.2200.100
8 227.2285.016
9 227.2420.050
10 227.4805.050
11 227.2200.500
12 227.2200.200
MAJOR
CHILI
223.5080.000
0 227.1420.050
1 227.5030.010
2 227.1400.050
3 227.1601.050
4 227.5080.020
5 227.2020.018
6 227.5080.0 30
7 227.2200.100
8 227.2285.016
9 227.2420.050
10 227.4805.050
11 227.2200.500
12 227.2200.200
0
10
9
11
7
12
8
6
5
4
3
2
1
A 1 x
B 2 x
C 1 x
D 1 x
E 1 x
F 2 x
G 5 x
H 5 x
I 3 x
J 1 x
K 1 x
L 1 x
M 2 x
N 3 x
explodedview
