Page 10
Assembly instructions (continued)
STEP 1 ALL MODELS: Attach the hood handle to the hood.
WHAT YOU NEED:
2 x Washers 15 / 6.5*mm
2 x M6*12mm Round Head Screws
2 x Handle Bezels
(Above components are factory pre-assembled onto the hood handle not in the bolt pack)
CAREFULLY OPEN THE BBQ HOOD TO ACCESS THE HANDLE HOLES FROM INSIDE
From inside the hood, with the hood open, fit the screw first through the washer, then through the
hood, then through the bezel and into the hood handle as shown. Tighten firmly.
Remove the screw on the Handle View from inside the hood: View from outside the hood:
STEP 2 ALL MODELS: Attach the grease channelling tray brackets.
WHAT YOU NEED
2 x Grease Channelling Tray Brackets
4 x M4*8mm Round Head Screws (4B)
4 x M4*8mm Round Head Screws (2B)
Screw the left and rights side brackets to the separator panel. Make sure the stopper screw heads
are at the top back inside edge as shown below.
To Next Page
