Assembly instructions (continued)
STEP 18 ALL MODELS: Fit the warming rack.
The warming rack hooks onto the side windshield and into the locating holes in the windshield
back panel. If you have a cart, the warming rack can hook onto the back of the cart when not
required.
STEP 19 DELUXE 4 BURNER MODELS ONLY: Attach the rotisserie
a) Assemble the motor bracket
WHAT YOU NEED
1 x Motor Bracket including:
2 x Washer
2 x M6 Hex Nut
2 x M6*15mm Screw
Remove the two M6*15 screws, washers, hex nuts screws that come pre-assembled with the
motor bracket. Use them to assemble the bracket to the left wind shield by using as shown.
