R5911227 /02 Coronis Fusion 4MP / 6MP 57
Net weight packaged Version with Protective cover: 22.3 kg (without optional accessories)
Version with Optical glass: 23.1 kg (without optional accessories)
Tilt -5° to +25°
Swivel -30° to +30°
Pivot N/A
Height adjustment range 100 mm
Mounting standard VESA (100 mm)
Screen protection Protective, anti-reflective glass cover Optical bonded protective, anti-
reflective glass cover (optional)
Recommended modalities All digital images, except digital mammography
Certifications FDA 510(k) K191845 for General Radiology pending
CE1639 (MDD 93/42/EEC; A1:2007/47/EC class IIb product)
CCC (China), KC (Korea), PSE (Japan), BIS (India), BMSI (Taiwan), EAC
(Russia, Kazakhstan, Belarus, Armenia and Kyrgyzstan)
Safety specific:
IEC 60950-1:2005 + A1:2009
EN 60950-1:2006 + A1:2010 + A11:2009 + A12:2011 + A2:2013
IEC 60601-1:2005 + A1:2012
EN 60601-1:2006 + A1:2013 + A12:2014
ANSI/AAMI ES 60601-1:2005 + R1:2012
CAN/CSA C22.2 No. 60601-1:2014
EMI specific:
IEC 60601-1-2:2014 (ed.4)
EN 60601-1-2:2015 (ed.4)
FCC part 15 Class B
ICES-001 Level B
VCCI (Japan)
Environmental:
China Energy Label, EU RoHS, China RoHS, REACH, Canada Health,
WEEE, Packaging Directive
Supplied accessories User guide
Documentation disc
System disc
Video cables
Mains cables
USB cable
Optional accessories Graphics board
Touch pad
QA software QAWeb
Warranty 5 years, including 40000 hrs backlight warranty
Operating temperature 0 °C to 35 °C (15 °C to 30 °C within specs)
Storage temperature -20 °C to 60 °C
Operating humidity 20% to 85% (non-condensing)
Storage humidity 20% to 85% (non-condensing)
