8. Important information
Maximum luminance
720 cd/m²
DICOM calibrated luminance
(ULT off)
500 cd/m²
Contrast ratio (typical) 1000:1 (panel typical)
Response time (Tr + Tf) 18 ms
Scanning frequency (H; V) 30-150 kHz; 15-80 Hz
Housing color Black / Silver
Video input signals DVI-D Dual Link (2x), DisplayPort (2x)
Video inout terminals NA
USB ports 1 upstream (endpoint), 3 downstream
USB standard
2.0
Power requirements (nominal)
100-240V
Power consumption (nominal) 125W
Power save mode Yes
Power management DVI-DMPM, DP-DMPM
Dot clock 280 MHz
OSD languages English, German, French, Dutch, Spanish, Italian, Portugese, Polish,
Russian, Swedish, Chinese (simplified), Japanese, Korean, Arabic
Dimens ions with stand (W x H
xD)
Portrait: NA Landscape: 731 x 580~676 x 265 mm
Dimensions w/o stand (W x H
xD)
Portrait: NA Landscape: 731 x 485 x 141 mm
Dimensions packaged (W x H
xD)
869 x 764 x 400 mm
Net weight with stand 26.5 kg
Net weight w/o stand
20 kg
Net weight packaged with
stand
36.5 kg
Net weight packaged w/o stand N/A
Height adjustment range 96 mm
Tilt
-5° / +25°
Swivel -45° / +45°
Pivot
N/A
Mounting standard
VESA (100 mm)
Screen protection Protective, non-reflective glass cover
Recommended modalities
CT, MR, US, DR, CR, NM, Film
Certifications CE0120 (MDD 93/42/EEC; A1:2007/47/EC class IIb product), CE -
2004/108/EC, IEC 60950-1:2005 + A1:2009 (2ND EDITION), IEC
60601-1:2005, ANSI/AAMI ES 60601-1:2005 + C1:2009 + A2:2010,
CAN/CSA C22.2 No. 60601-1 (2008), DEMKO - EN 60601-1:2006,
EN 60601-1-2:2007, CCC - GB9254-2008 + GB4943.1-2011 +
GB17625.1-2012, KCC, VCCI, FCC class B, ICES-001 Level B, FDA
510(k), RoHS.
User Guide
Quick Installation Sheet
Video cables (2x DVI Dual Link, 2x DisplayPort)
Main cables (UK, European (CEBEC/KEMA), USA (UL/ CSA; adaptor
plug NEMA 5-15P), Chinese (CCC))
USB 2.0 cable
Supplied accessories
External power supply
50 K5902055 CORONIS FUSION 6MP 14/11/2014
