Manual 2100-680
Page 7 of 18
REMOTE SENSOR ACCESSORIES
TABLE 2
Remote Sensor Accessories
Model Number Description
8612-058 Wall-Mounted Temperature Sensor
8612-059
Wall-Mounted Temperature Sensor with Override Button
and Occupancy Status LED
NOTE: If one or multiple sensor(s) is/are connected
into the RS terminal, the internal temperature
sensor is automatically disabled. Disconnecting
the sensor(s) in RS terminal will re-activate the
internal sensor.
Remote mount temperature sensors inputs use 10K
type 2 NTC thermistors.
Features
• Each sensor can be configured for various
averaging combinations.
See Advanced Programming & User Interface
Setup Guide (manual 2100-681) for configuration
instructions.
˚C ˚F Kohm
-40 -40 324.3197
-35 -31 234.4009
-30 -22 171.3474
-25 -13 126.6109
-20 -4 94.5149
-15 5 71.2430
-10 14 54.1988
-5 23 41.5956
0 32 32.1910
5 41 25.1119
10 50 19.7390
15 59 15.6286
20 68 12.4601
25 77 10.0000
30 86 8.0694
35 95 6.5499
40 104 5.3467
45 113 4.3881
50 122 3.6202
55 131 3.0016
TABLE 3
Temperature vs. Resistance for
10K Ohm NTC Thermistor
(R25˚C = 10KΩ±3%, B25/85˚C = 3975K±1.5%)
