Bardiani B925 - Mixproof Valve B925 - B925 B - B925 V - B925 A

Instruction, Use and Maintenance Manual
EN-IST-B925-0218
12 Mixproof valve B925 - B925B - B925V - B925A
NO. DESCRIPTION NO. DESCRIPTION
1 Bottom body/double body
2 Upper shutter 70 Sealing ring
4 Sealing ring 74 Air connector
9 Cylinder 75 Air connector
11 Pin 77 Nut
12 Sealing ring 78 Sealing ring
13 Central piston 81 Sealing ring
14 Sealing ring 82 Sealing ring
16 Sealing ring 83 Sealing ring
17 Bush 85 Secondary spring
18 Buffer 90 Sealing ring
19 Sealing ring 91 Sealing ring
24 Air connector 92 Intermediate body
31 Spring 93 Intermediate valve member
33 Clamp 94 Sealing ring
34 Screw 96 Sealing ring
35 Assembly 101 Screw
40 Cap 106 Bush
42 Upper body 108 Sealing ring
44 Sealing ring 120 Bush
45 Steam barrier 121 Sealing ring
47 Sealing ring 126 Sealing ring
50 Gasket holder disc 154 Thickness
51 Lower shutter 168 Bush
52 Cap 193 Bush
53 Lower piston 199 Clamp
55 Sealing ring 226 Sealing ring
58 Drive sleeve 240 Sealing ring
60 Sealing ring 242 Sealing ring
61 Sealing ring 245 Guide pin
62 Sealing ring 270 Sealing ring
63 Sealing ring
64 Bush
66 Upper piston
69 Sealing ring
Legend:
00* = component present only on the B925B valve.
00** = component present only on the B925 valve.
00*** = component present only on the DN25 - 40 and DN65 valve.
= component present in the spring block (supplied assembled)
