Bardiani B925 - Operation

Instruction, Use and Maintenance Manual
EN-IST-B925-0218
6 Operation
1. EXTERNAL CIP CONNECTION (B925B only)
A = CIP external inlet
A = CIP external outlet
CAUTION!
Hand crushing hazard. During operation there is a crushing hazard
caused by the washing pin or the guide pin (when present).
2. VALVE INSPECTION BEFORE OPERATION:
- Supply air to the actuator;
- Power the valve (via the control unit);
- Open and close the valve several times;
- Check that the valve works correctly and accurately.
1 = Opening
2 = Top lift
3 = Bottom lift
CAUTION!
Hand crushing hazard. During operation there is a crushing hazard
caused by the washing pin or the guide pin (when present).
14
A
B
3
1
2
