Bardiani B925 - Mixproof Valve B925 - B925 B Diverter

Instruction, Use and Maintenance Manual
EN-IST-B925-0218
15 Mixproof valve B925 - B925B Diverter
NO. DESCRIPTION NO. DESCRIPTION
1 Bottom body/double body 77 Nut
2 Upper shutter 78 Sealing ring
4 Sealing ring 81 Sealing ring
9 Cylinder 82 Sealing ring
11 Pin 83 Sealing ring
12 Sealing ring 85 Secondary spring
13 Central piston 90 Sealing ring
14 Sealing ring 91 Sealing ring
16 Sealing ring 92 Intermediate body
17 Bush 93 Intermediate valve member
18 Buffer 94 Sealing ring
19 Sealing ring 96 Sealing ring
24 Air connector 101 Screw
31 Spring 106 Bush
33 Clamp 108 Sealing ring
34 Screw 120 Bush
35 Assembly 121 Sealing ring
40 Cap 126 Sealing ring
42 Upper body 154 Thickness
44 Sealing ring 193 Bush
50 Gasket holder disc 199 Clamp
51 Lower shutter 240 Sealing ring
52 Cap 242 Sealing ring
53 Lower piston 245 Guide pin
58 Drive sleeve 270 Sealing ring
60 Sealing ring
61 Sealing ring
62 Sealing ring
63 Sealing ring
64 Bush
66 Upper piston
69 Sealing ring
70 Sealing ring
74 Air connector
75 Air connector
54
