2
Phillips Screwdriver
Safety Glasses
Line Level
Tape Measure
Drill
#2 Square Drive Bit
Gate Hardware (Latch)
2" Wood Blocks
TOOLS/MATERIALS NEEDED:BEFORE YOU BEGIN:
Vinyl gate posts require an internal support
system for weight-bearing purposes
therefore a post stiffener is required. Post
stiffener needs to be purchased separately.
WARNING:
• Improper installation of this product can result in personal injury. Always wear safety goggles when
cutting, drilling and assembling the product.
• Incorrect installation may cause harm to the gate or individual.
• Not pool code approved.
• Do not allow children to play with the gate.
NOTICE:
• DO NOT attempt to assemble the kit if parts are missing or damaged.
• DO NOT return the product to the store, for assistance or replacement parts call: 1-800-336-2383.
Top View of Routed Post
Fence
Purchased
Stiffener
Lattice Top Gate
Component list:
Description
Lattice
Boards
Top Rail
Middle Rail
Bottom Rail
Gate Uprights
Upright Inserts
Upright Caps
Screws
Lattice Channels
Vinyl Cement
Hinges
U-Channels*
Upright
Cap
Lattice
Lattice Channels
Gate
Upright
Upright
Inserts
Hinges
Screws
Vinyl
Cement
Top Rail
Middle Rail
Bottom Rail
Lattice Top
NOTE: Components shown are for visual reference only and may not depict the exact style of
your product. Please see product label for correct number of pieces.
*NOTE: Not all vinyl privacy gates
include U-Channels.
BoardsBoards
U-Channels*U-Channels*
To obtain and review a copy of the warranty please visit barretteoutdoorliving.com. You may also contact
us at 1-800-336 2383 or email Cs.outdoorliving@ebarrette.com
To Next Page
