Scope:
EXcite
USER MANUAL
BHB 125 / BHB 150
g
Date:
24.11.2014
Rev.:
A
Checked by:
T.H.
Approved by:
EGT
Page:
Page 10 of 12
Document no.:
57-DSP-5
WEB: www.bartec-technor.no PHONE: +47 51 84 41 00 E-MAIL: mail@bartec-technor.no
Xenon Beacon
The Xenon Beacon provides flashing status.
Use DIP Switch with 2 binary codes on the Xenon Beacon PCB (see fig. 5/7) for frequency adjustment.
Xenon Beacon Flashing Frequency Adjustment
DIP Switch: ON = 1, OFF = 0
S1/S2: ON = Connect with COM
OFF = Disconnect with COM
S1/S2
DIP
Switch
S1=OFF
S2=OFF
S1=ON
S2=OFF
S1=OFF
S2=ON
S1=ON
S2=ON
1
1
Alarm stage
1
Alarm stage
2
Alarm stage
3
Alarm stage
4
0
0
45
times/min
60
times/min
75
times/min
120
times/min
0
1
80
times/min
100
times/min
120
times/min
150
times/min
1
0
90
times/min
120
times/min
150
times/min
150
times/min
10.0 CABLE GLAND
The BHB series product has cable gland entries. Only cable glands approved for Ex ‘d’ applications can be
used, which must be suitable for the type of cable being used and also meet the requirements of the Ex
‘d’ flameproof installation standard EN 60079-14.
SAFETY WARNING: If the BHB is used at high ambient temperatures, i.e. over +40ºC, then the cable entry
temperature may exceed +70ºC and therefore suitable heat resisting cable glands must be used, with a rated
service temperature of at least 95ºC.
If a high IP (Ingress Protection) rating is required, a suitable sealing washer must be fitted under the cable
gland.
When only one cable entry is used, the other one must be closed with an Ex ‘d’ flameproof blanking plug,
which must be suitably approved for the installation requirements.
