Tech 400 User Guide R5 4/1/08
8
Tech 400 User Guide R5 4/1/08
21
Once a read is completed:-
The TPM id is briefly displayed, then the tool automatically moves
o
nto the next wheel position- the arrow moves around the
vehicle:-
Awaiting the next read
Once all 4 TPM’s have been read, results can be viewed,
exa
mined on a pc, or the communications sub menu can be
accessed (see ‘Vehicle Communication’ section.
When there is an insufficient amo
unt of power remaining in the
battery then the Bartec Tech 400 will flash its battery icon for two
seconds, save all of the TPM Data and then power itself off.
When the battery is being ‘fast charged’ the indicator segments
‘wa
lk;’ from left to right- see the charging paragraph.
Test Indicator
This status line Indicator only appears on the select by vehicle
menu
. It confirms that a vehicle has been sufficiently selected to
fully identify the TPM type.
If the Indicator is not visible when navigating the vehicle screens,
th
en pressing the Test Key will read the last TPM Type read/
selected.
Note when selecting by vehicle, the Tech 400 will ‘look ahead’
and
display the test indicator when sufficient selection has been
made- this may be prior to all available options (e.g. model, year)
having been navigated.
Results Data Available Indicator
This status line Indicator confirms
that TPM data is available for
viewing on the screen (using the View TPM Data command from
the main menu) or via a PC when the Bartec Tech 400 is in its Mass
Storage Device mode (See Audit System on page
23).
The Tech400 only stores up to 5 TPM
data records at any one time.
When there is no data present, the TPM Data Indicator will not be
vi
sible.
