ITEM
NO.
PART NO. DESCRIPTION QTY. REMARK
101 N/A BASE UNIT 1 6/8/2004
102 20442 STABILIZER RING 1 8/21/2007
103 10442 SHOULDER BOLT 4 8/21/2007
104
20562
20611
HANDLE ASSEMBLY, STANDARD
HANDLE ASSEMBLY, EUROPEAN
1
6/8/2004
1/17/2008
105 11003
SQUARE KEY, 3/16” x 1 7/8”LG
1
8/16/2007
106 ENGINE ENGINE 1 6/8/2004
108 11113 MUFFLER DEFLECTOR 1 8/21/2007
109 10902 WASHER, LOCK, 5/16” 4 6/8/2004
110 10901 HEX NUT, 5/16-18UNC, GRADE 5 4 6/8/2004
111 21029 CLUTCH, 1” BORE 1 11/07/12
112 14285 SHEAVE 1 8/16/2007
113 10208 SQUARE KEY, 3/16” x 1 1/2”LG 1 6/8/2004
114 11178
BELT, B29
1
8/16/2007
115 21065 BELT GUARD 1 8/16/2007
116 10902 WASHER, LOCK, 3/8” 1 6/8/2004
117 10901
HEX NUT, JAM, 3/8”-16UNC
1
6/8/2004
118 20448
GUARD RING
1
6/8/2004
120 50026
WASHER, FLAT, 1/2”
4
6/8/2004
123 11029
STUD, 3/8”-16UNC x 1 3/4”LG
1
8/16/2007
124 20171
HOIST HOOK (optional)
1
6/8/2004
125 30041
fscs, 5/16”-24UNF x 3/4”LG (optional)
4
6/8/2004
126 20512
CARRY BAR ASSEMBLY (optional)
1
6/8/2004
127 20442
STABILIZER RING
1
6/8/2004
128 10442
SHOULDER BOLT
4
6/8/2004
138 14650
STUD, ENGINE MOUNT
4
4/15/2011
139 10919
WASHER, FLAT, 5/16”
2
4/15/2011
140 10104
SPACER, 5/16”
4
4/15/2011
141 10919
WASHER, FLAT, 5/16”
2
4/15/2011
142 13781
HHCS, 1/2-13UNC x 1”LG
4
4/15/2011
143 10009
WASHER, LOCK, 1/2”
4
4/15/2011
144 50026
WASHER, FLAT, 1/2”
4
4/15/2011
145 11800
OIL DRAIN HOSE (NOT SHOWN)
1
4/15/2011
PARTS LIST 1
WALK-BEHIND TROWELS
GENERAL ASSEMBLY - B446
5
