Bartell B446 - Clutch Assembly Parts

ITEM
NO.
PART NO. DESCRIPTION QTY. REMARK
701 11045 SPINDLE 1 8/21/2007
702 11044 BEARING 1 8/21/2007
703 21046 DRUM W/BUSHING 1 8/21/2007
704 11012
BUSHING
1
8/21/2007
705 11014
WEIGHT (SHOE)
4
8/21/2007
706 10759 SPRING 1 8/21/2007
707 11015
FACE PLATE
1
8/21/2007
708 50117 SET SCREW 2 8/21/2007
PARTS LIST 6
WALK-BEHIND TROWELS
CLUTCH ASSEMBLY - 21029 (1” SHAFT)
ITEM
NO.
PART NO. DESCRIPTION QTY. REMARK
701 11045 SPINDLE 1 8/21/2007
702 11044 BEARING 1 8/21/2007
703 21046 DRUM W/ BUSHING 1 8/21/2007
704 11012 BUSHING 1 8/21/2007
705 11014 WEIGHT (SHOE) 4 8/21/2007
706 11013 SPRING 1 8/21/2007
707 11015
FACE PLATE
1
8/21/2007
708 50117 SET SCREW 2 8/21/2007
PARTS LIST 7
WALK-BEHIND TROWELS
CLUTCH ASSEMBLY - 21005 (1” SHAFT)
