DFG280 FLOOR GRINDER
OWNER’S MANUAL AND PARTS BOOK
14
OIPB – S30004
DFG280 OVERVIEW – PARTS LIST 1
Item #
Part #
Description
QTY
Remarks
101
905350
MAIN BODY PLATE
1
102
905351
HANDLE (BOTTOM SECTION)
1
103
905352
HANDLE (TOP)
1
104
905353
CONNECTOR
1
105*
905354
GRINDING PLATE ADAPTOR
1
107
905356
SHROUD
1
108
905357
FLOATING SHROUD
1
109
905358
EDGING SHROUD
2
110
905359
EXHAUST BRACKET
1
111
12116
MOTOR
1
112
905361
AXLE (REAR)
1
113
905362
AXLE SLEEVE
1
114
905363
PIVOT PLATE (10MM)
2
115
905364
PIVOT PLATE
2
116
905365
PIVOT PLATE PACKER
2
117
905366
CLAMPING BAR
4
118
905367
ELECTRICAL BOX PLATE
1
119
905368
END CAP
2
120
905369
END CAP (WITH HOLE)
1
121
905370
ROLL PIN, M6x20MM
2
122
905371
BEARING
4
123
905372
BEARING SPACER
4
124
905373
EXTRACTION TUBE
1
125
905374
FLEXI-COUPLING
1
127
905376
DUST SKIRT (580MM)
1
128
905377
DUST SKIRT (140MM)
1
130
905380
HANDLE GRIP (BACK)
1
131
905380
HANDLE GRIP (FRONT)
1
133
906013
WHEEL (REAR)
2
134
907379
LOCKING PIN
2
135
909104
HANDLEBAR GRIP
2
148
12128
CABLE GLAND EMC
1
149
12120
MOTOR STARTER
1
150
12118
UNDER VOLTAGE COIL
1
151
12121
ENCLOSURE W/ STOP BUTTON
1
152
153
TI/009
TUBE INSERT (BLACK)
2
*Only required if using grinding plate, instead of Slidemag or Tmag plate.
