21
BUSHING PLATE PARTS LISTING
1 E82773 Washer, Flat, M10 x 21 x 2, Zinc 2
2 E88594 Washer, Split Lock, M6 Zinc 8
3 E88601 Washer, M10 x 30 x 2.5, Zinc 1
4 E88626
Bearing, Ball M-19 OD x M10 ID x M5 Thk, Sealed 4
5 E88628 Snap Ring, External, M10, Zinc 3
6 E88643 Bushing, Flange 10 ID x 15 OD x 10 L, Bronze 1
7 E88648 Bushing, Flange 15 ID x 19 OD x 16 L 1
8 E88649 Screw, Set, M6 x 6 Cup Point, Zinc 6
10 E88650 Foot Pedal Axle 1
11 E88651 Stiffing Rod 1
12 E88654 Foot Pedal Link Weldment 1
13 E88657 Axle, Front Wheels 1
14 E88658 Front Wheel 2
15 E88659 Spacer, Right Wheel 1
16 E88661 Spacer, Inner Wheel 1
17 E88662 Pivot Linkage Lever Right Weldment 1
18 E88663 Right Lift Arm Weldment 1
19 E88664 Lower Frame Bushing Plate Weldment 1
20 E88688 Bolt, M6 x 12, Hex Head, Zinc 8
Item# Part # Description Qty. Item# Part # Description Qty.
